The Universal Top-of-Pole Mount BS-TP004

Description

Best Solar versatile Pole Top solution BS-TP004 is designed to satisfy the most common small-medium solar power needs, particularly in the wireless and security infrastructure markets. it is a very sturdy and straightforward pole mounting solution for small area solar photo voltaic (PV) needs. With its user-adjustable angle settings, it can support installations in a wide range of locations.

The mount assembles easily and can be used to construct 400Wp (4 x 100Wp modules) or 680Wp (4 x 170Wp modules) stations, whether used to connect directly to a grid with grid tied inverter(s) to offset power usage, or charge a battery bank for remote applications. With modules commonly available up to 170W+, even greater power production can be achieved in a single installation. Made with galvanized steel, anodized aluminum rails and stainless steel hardware, the structure is designed for years of durability in harsh environments. With the array centrally balanced on the pole top, manual seasonal orientation adjustments can be made easily.

In addition, the BS-TP004 supports:

Up to four PV panels with a combined width of up to 52 inches.

A pole diameter of 4.0 inches (requires a properly anchored schedule 40 pipe).

Schedule 40 Pipe Not Included.

Features

All components required to mount 4 x 36 cell modules, nominally 100 through 170 watt modules

Easy tilt solar panel adjustment ensures optimal alignment in a range of environments, year around

Heavy-duty, corrosion-resistant aluminum means long-term reliability and value

Compatible with most commercially available solar panels

Easy installation and affordable pricing help slash total cost of installation

Multiple product offerings accommodate a wide range of solar mount application scenarios

Galvanized Steel, and Anodized Aluminum construction

Includes integrated equipment ground solution

- Tilts ranging from 10 to 65 degrees

 45 inches clearance to front of array for snow shedding

 Includes flanged vertical post and anchors

Applications

 1000W+ remote power generation

Oil and gas monitoring stations

Security monitoring

 Wireless stations

 Grid connected power supplement
