Name:Boat Solar Panel Tilting Mounting Kit - Stainless Steel Swivel Bracket
Model No.:BS-BOA2
Material:316 Stainless steeL
Packing:2pcs per set
Maximum power:250 Watt
Mount panel qty:1 solar panel
Tilt Range:30-60 degree
Warranty:5 years

Product Description


 A pair of 2mm stainless steel (316L) solar panel brackets designed with canalboats and vehicles in mind, supplied with marine standard cable glands and anti tamper bolts & bit.

Allow your solar panels to both tilt and swivel throughout the year, maximising the sun's energy whilst providing excellent ventilation. This can improve the power of your panels by up to 40%, perfect for smaller systems where efficiency is key. *Standing at just over 25cm high and 16cm  wide they're designed to maximise the angle of your panels whilst being low enough for most bridges and tunnels.

Using any padlock attach your panel securely to the roof via an integrated 8mm stainless steel chain that secures directly to the bracket, keeping your panels safe. The anti tamper bolts secure the bracket to your roof for maximum security deterring even the most determined of thieves.

Using M10 for both bolts and glands means you only need to drill six identical holes, saving both time and money on tools or labour whilst providing a safe and secure mounting solution.

Don't get these brackets confused with cheap copies or aluminium brackets on the market, these are laser cut stainless steel. Very strong can support panels up to 250w. Fitted as standard to all our solar installations on over 1000 narrow boats.
