Product Center
Name: | Premium XL 160W 12V mono Motorhome Solar System |
---|---|
Model No.: | BSPRM160 |
Dimensions: | 1480mm x 680mm x 35mm |
Weight: | 11.2 kg |
Open Circuit Voltage: | 22.4V |
Short Circuit Current: | 9.06A |
Max Power Voltage: | 18.30V |
Max System Current: | 8.74 A |
Max System Voltage: | 1000VDC |
Number of Cells: | 36 |
Power Allowance Range: | 3 |
Operating Temperature: | -40~+85°C |
Connection+Cable: | MC4, 4mm², 900mm |
Standard Test Conditions (STC): | AM1.5, 1000W/m², Cells Temperature 25°C |
Product Description
Description
The Best Solar 160W12V Premium-XL Motorhome Solar System is the perfect solar set for the self-sufficient power supply in your motorhome or caravan and leaves nothing to be desired. The installation does not even take two hours - experienced hands are much faster. The expected daily output (April to October) is an average of 600Wh / day (max 1200 Wh on sunny days in Germany). The system is best suited to charge 12V AGM, GEL or lead-acid batteries.
160W motorhome complete set: simple, proven, high quality
The set contains all the components you need to charge your batteries mobile. The special feature of our solar systems for campers: We use a TÜV-tested mounting system that can be easily glued. The module can be unscrewed from the spoiler at any time, should you need to look at the area under the solar module. Each of our sets is designed so that it can be extended by another module in the same performance class.
If you want to remove the spoiler completely this is not a problem either. The supplied Sikaflex Adhesive Set by Sika contains not only the mounting adhesive but also a solution for removing the adhesive and the residues. Even at the critical point, the cable entry into the interior of the motor home, we have paid special attention to quality. The supplied cable gland is made of the same sturdy material as the roof spoiler for the solar modules and simply glued on with Sikaflex. The connection is completely waterproof and lasts many, many years.
Kit Includes
1x PWM solar charge controller - 12V 20A PWM controller with display, load output, USB and more.
1x BestSolar 160W 12V - monocrystalline solar module equipped with SWM Solarworld cells
1xBestSolar ABS cable entry 1-way - white with waterproof PEG screw connection
1x BestSolar 68cm ABS mounting profiles (1 pair) - for fixing the solar modules
1x BestSolar 5m 2x4mm cable - connection cable solar module to solar charge controller in motorhome version
1x BestSolar 1.5m 2x6mm 30A battery connection cable - connection cable solar charge controller to battery
1x BestSolar battery pole terminals (1 pair)
1x Sikaflex 252 assembly adhesive set -(suggest you buy on local)
The high quality PWM solar charge controller
The PWM solar charge controller offers a large, comfortable LCD display and uses state-of-the-art charging technology. A large display informs the user with the help of symbols about all operating conditions. The state of charge is visually displayed in the manner of a fuel gauge. Data, such as As voltage, current and state of charge, can also be displayed digitally as a number on the display. In addition, the controller has a KWh counter, which the user can reset himself. Also, a controllable load output as well as 2 USB 5V outputs are integrated into the controller and provide your 12V and 5V DC consumers with power. The complete range of functions can be found in the documentation of the charge controller
The BestSolar 160W 12V SWM solar module
In the production of our modules only monocrystalline solar cells of the highest quality level are processed. Currently Waver are used by the German quality manufacturer Solarworld. The module has a frame made of anodized aluminum and has a specially hardened tempered glass ESG, which makes it particularly resistant to external influences (weathering, etc.).
The expected daily output (April to October): on average 640Wh / day (max 1280 Wh on sunny days in Germany
Dimensions solar module: 1480mm x 680mm x 35mm (HxWxD).
professional solar mounting system
Spoiler profiles are the first choice especially for caravans and motorhomes when it comes to a clean mounting of the solar modules. If you mount the modules in the direction of travel, wind noise is no longer an issue (this also applies to alcove vehicles). Due to the closed design of the spoiler, no branches or the like can get caught under the solar modules.
Spoiler dimensions: L x W x H: 68cm x 8.9cm (of which about 3cm module per spoiler) x 6.5cm.
Key Features
We are the only manufacturer to offer you a complete motorhome solar system, in which all components are delivered from our own production
The premium mobile system class is probably the most sold RV solar system on the market and has already been successfully installed thousands of times. In addition, the premium mobile series established itself more than 8 years ago on the market and was repeatedly improved due to customer experience and constantly supplemented by technical innovations.
As a customer, you benefit from a product that is highly developed and reliable and that at a solid price.
