Name:SM-50W18V Semi-flexible Solar Panel
Model No.:KL50W-36M-SF
Dimensions:520mm x 670mm x 2.5mm
Weight:1.40kg
Open Circuit Voltage:21.3V
Short Circuit Current:3.03A
Max Power Voltage:17.8V
Max System Current:2.81A
Max System Voltage:500VDC
Number of Cells:36
Power Allowance Range:±3
Operating Temperature:-40~+85°C
Connection+Cable:1M cable+SAE connector
Standard Test Conditions (STC):AM1.5, 1000W/m², Cells Temperature 25°C

Product Description

Description

Flexible solar panel ( SM series)

1. The short distance between the multi-gate lines can greatly increase the current during the transmission process. The long distance between the conventional solar cell buses generates more power loss during the transmission process.

2, Unique mesh design, based on direct light, higher light utilization and less shadow

3, low temperature coefficient, power temperature coefficient -0.3938% / °C. In the summer when the outside temperature reaches 80 °C, with Multi-wire electrode technology, the front and rear ends of the link can be used as a heat sink and help absorb heat from the surface, reduce power loss.


Features

 1、Semi-Flexible solar panels with bendable

2、The maximum system voltage is 100VDV

3、Lightweight and thin: Only 1.4KG

4、The panel size: 520*670*3mm

5、surface ETFE and backboard TPT



Typical Applications

* Trickle charger for 12v batteries

* Maintenance charging for boats at mooring

* Maintenance charging for emergency vehicles

* Sole source charging for auxiliary recreational equipment,RVs,jet,skis,traffic signs,small appliances&other electronics



Install:

*Holes on panels are pre-drilled for fast mounting and securing, perfect for non-permanent installations

*Can be affixed by adhesive, grommets or Velcro (with which you can easily attach or detach the panels)

*Can be installed without costly structural roof reinforcements
