Product Center

Name:200W solar charging kit for 12V/24V battery in a motorhome, caravan, campervan, boat or for any off-grid
Model No.:BSPRM200
Dimensions:1580mm x 810mm x 35mm
Weight:15.5 kg
Open Circuit Voltage:45.5V
Short Circuit Current:5.80A
Max Power Voltage:38.8V
Max System Current:5.15 A
Max System Voltage:1000VDC
Number of Cells:72
Power Allowance Range:3
Operating Temperature:-40~+85°C
Connection+Cable:MC4, 4mm², 900mm
Standard Test Conditions (STC):AM1.5, 1000W/m², Cells Temperature 25°C

Product Description

Description


  • One of the most powerful solar charging kits for vehicles, boats or off-grid power systems - up to 14A charging current per hour in full bright sunlight

  • High efficiency 20A MPPT solar charge controller with automatic 12V / 24V selection to extract the maximum power from the solar panel

  • Comes complete with all mounting brackets, cables, waterproof cable gland and connectors, and a detailed user manual

  • Built-in LCD display to show real-time charging parameters such as voltage, current and power for the solar panel and the battery



Kit Includes

- High quality 200W monocrystalline solar panel
- 20A 12V/24V high efficiency MPPT solar charge controller with an LCD display
- Set of 4 corner plastic mouting brackets for bonding to the roof
- 2 sets of 2 side mounting brackets for bonding to the roof
- Waterproof double entry cable gland
- 5m 4.0mm extension cable with waterproof MC4 connectors
- 5m of thick 6.0mm twin core battery cable

This is one of the most powerful solar charging kits for vehicles, boats or off-grid power systems. It can generate up to 14A charging current when charging a 12V battery, so a typical 80Ah battery will be charged from 0% to 100% in only 5 hours of bright sunlight.

200W monocrystalline solar panel included with the kit has been manufactured to the highest standards, thoroughly tested and labelled with a unique serial number for further quality control and better warranty protection.
