Name:100w MonoCrystalline Folding Solar Panel Kit for boat caravan home
Model No.:KL-F-100W
Peak power:100W
Maximum power voltage:17.6V
Maximum power current:5.64A (2 x 2.82A)
Open circuit voltage:21.36V
Short circuit current:6.2A (2 x 3.1A)
Maximum System Voltage:1000V
Weight:12.6kg
Dimensions:675 x 540 x 70mm
Power Allowance Range:3
Operating Temperature:-40~+85°C
Connection+Cable:MC4, 4mm², 900mm
Standard Test Conditions (STC):AM1.5, 1000W/m², Cells Temperature 25°C

Product Description

Description

This 100W BestSolar folding solar kit includes all you need for charging 12V battery:

High efficiency 50W + 50W folding solar panels

Advanced fully automated 10A solar charge controller with many protection functions

Adjustable aluminium stand, handle and latches

5m cable with a battery plug and a fuse

Battery crocodile clips for ease of connection

Quality protective case

Installation manual


Key Features

The kit has several important features which make it a truly unique premium quality product:

High efficiency 50W + 50W folding monocrystalline solar panels are made of high quality solar cells

100% Ready to Use Solar Panel Kit

Portable and Lightweight at only 11.3kg

Mono-Crystalline Cells Absorb Sunlight and are Shade Tolerant

Hail Resistant Tempered Glass

Compatible with the Most Common Connectors

Flexible with a Foldable Frame, an Adjustable Angle with Lockable Support Stands

Eco-Friendly with Quiet Operations

Hassle Free with an Easy Setup

Inclusive of a Solar Regulator,2m Cable and Foam-Padded Bag with Accompanying Shoulder Strap

Quality Assured with a Lifetime Output Guaranteed

Product Support with the Best After Sales Assistance

Created with Quality German Standards at a Most Affordable Price

Achieved the Highest International Standards: ISO 9001 And ISO14001 and Certified with TUV, IEC61215, IEC61730, CE and UL

25 Year Warranty on Cells

High efficiency 50W + 50W folding monocrystalline solar panels are made of high quality solar cells

Storage bag is not just a dust cover - it's a protective case made with a layer of foam which can prevent accidental damages to the frame and glass

Advanced fully automated 10A solar charge controller provides complete overcharge, reverse current, incorrect polarity and short circuit protection

The controller uses PWM technology and supports several battery types with different charging parameters for maximum efficiency of charging

The kit is very easy to set up and install, you can start using it in seconds.
