Product Center

Name:60W 12V mono solar panel 680×576
Model No.:KL60W-36M-6
Dimensions:680mm x 576mm x 35mm
Weight:6.0g
Open Circuit Voltage:21.5V
Short Circuit Current:3.95A
Max Power Voltage:17.8V
Max System Current:3.50A
Max System Voltage:600VDC
Number of Cells:36
Power Allowance Range:5
Operating Temperature:-40~+85°C
Connection+Cable:MC4, 4mm², 900mm
Standard Test Conditions (STC):AM1.5, 1000W/m², Cells Temperature 25°C

Product Description

This 12v 60w Monocrystalline Solar Panel made with high efficiency 6" mono cells. Ideally suited panel for your motorhome or caravan. It is powerful enough to keep your battery charged over that long weekend away without starting the generator or plugging in to an external source.


This 12v 60w Solar Panel  is powerful enough to keep your battery charged over that long weekend away without starting the generator or plugging in to an external source


This  solar panel is powerful enough to keep your battery charged over that long weekend away without starting the generator or plugging in to an external source. Comes with MC4 connectors so they are easily added to a string and protected from the wet weather. Fully weather proof and professionally made with high quality components.



Top Material

10 years limited product warranty
15 years at 90% of the minimal rated power output
25 years at 80% of the minimal rated power output


High-quality

TUV,CE,RoHS certificate

High conversion efficiency

Low power tolerance of 0~+3% ;Low degradation under light exposure ;Can withstand high wind-pressure,snow load and extreme temperature ;Passing below test

IEC/EN 61215:2005;

IEC/EN 61730-1 A2

IEC/EN 61730-2 A1
